Kenford DYD300B-4-67, 12", 4 Ohm

Product No.:
6003255-X
ca. 2-3 days ca. 2-3 days (abroad may vary)
37,90 EUR

incl. 19% tax excl. Shipping costs

Piece:
Add to wish list
Price offer
Ask about product
Product Details

Kenford DYD300B-4-67, 12", 4 Ohm

The Kenford DYD300B-4-67 high-temp copper wire voice coil is wound on a durable polyimide former, guaranteeing maximum heat resistance and excellent mechanical strength. The Kenford DYD300B-4-67 features a specially designed force air ventilation system to ensure proper cooling of the voice coil for long hard play. The Kenford DYD300B-4-67 PA Woofer is a powerful upgrade for guitar, bass guitar or sound reinforcement cabinets.

Product Specifications
Nominal Diameter 12"
Power Handling (RMS) 250 W
Power Handling (Max) 500 W
Impedance 4 Ω
Frequency Response 47-4000 Hz
Sensitivity 93 dB
Voice Coil Diameter 50.8 mm (2")

Thiele-Small Parameters
Resonant Frequency (Fs) 50 Hz
DC Resistance (Re) 3.3 Ω
Total Q (Qts) 0.39
Compliance Equivalent Volume (Vas) 69.95 L

Materials of Construction
Cone Material Paper
Surround Material Cloth
Magnet Material Ferrite

Mounting Information
Overall Outside Diameter 304 mm (11-31⁄32")
Baffle Cutout Diameter 285 mm (11-7⁄32")
Depth 130 mm (5-1⁄8")
Mounting Holes 8

Kenford ZYD250B-8-4, 12", 4 Ohm
Brand Kenford
Model DYD300B-4-67
Part Number
 6003255
Weight 5 kg
