McGee 201846, 6.5", 8 Ohm

Product No.:
6003234
Shippingtime:
ca. 2-3 days ca. 2-3 days (abroad may vary)
24,90 EUR
incl. 19% tax excl. Shipping costs


McGee 201846, 6.5", 8 Ohm


The McGee 201846 high-temp copper wire voice coil is wound on a durable polyimide former, guaranteeing maximum heat resistance and excellent mechanical strength. The McGee 201846 features a specially designed force air ventilation system to ensure proper cooling of the voice coil for long hard play. The McGee 201846 PA Woofer is a powerful upgrade for guitar, bass guitar or sound reinforcement cabinets.

Product Specifications
Nominal Diameter 6.5"
Power Handling (RMS) 60 W
Power Handling (Max) 120 W
Impedance 8 Ω
Frequency Response 80-5000 Hz
Sensitivity 95 dB
Voice Coil Diameter 42 mm (1-21⁄32")

Thiele-Small Parameters
Resonant Frequency (Fs) 92 Hz
DC Resistance (Re) 7.2 Ω
Mechanical Q (Qms) 4.38
Electromagnetic Q (Qes) 1.32
Total Q (Qts) 1.01
Compliance Equivalent Volume (Vas) 13 ft³

Materials of Construction
Cone Material Paper
Surround Material Cloth
Magnet Material Ferrite

Mounting Information
Overall Outside Diameter 167 mm (6-37⁄64")
Baffle Cutout Diameter 140 mm (5-33⁄64")
Depth 90 mm (3-35⁄64")
Mounting Holes 4

McGee 201846, 6.5", 8 Ohm
Brand McGee
Model 201846
Part Number 6003234
Weight 1.32 kg (2 lbs.)
